1. Fully enclosed box, waterproof, dust-proof, and explosion-proof;
2. Uses fully automatic backwash filter to ensure entry into the equipment The water is free of impurities and improves service life.
3. The 3M CCC GB power cord andthe 10 meter high-pressure water outlet pipe make it easy to clean large areas without constantly relocating the machine.
① Electric Current protection range from 15A to 18A
② Power protection range from 7.5Kw to 8.5Kw
③ Voltage protection: 220V single phase 170V to 245V , 380V three phase 360V to 440V
④ Electric leakage protection at 30mAh
⑤ Open-phase protection for 380V three phase motor
⑥ Over heating protection for the motor at 120 degree
⑦ Error nozzle connect will not raise the electric current and voltage increase, motor will not broken, the pump is with the function of automatic pressure leakage.
⑧ New models for pump in 3000Hrs testing without the situation of oil leakage and water leakage
Model |
JNK-ZL-415T |
Motor Voltage(KW) |
4 |
Voltage(V) |
380 |
Frequency(HZ) |
50 |
Rotary Speed(rpm) |
1450 |
Rated Pressure(bar/PSI) |
150/2175 |
Max Pressure(bar/PSI) |
170/2450 |
Flow Volume(L/min /GPM) |
|
Nozzle Model |
055 |
Pump Model |
JNK-1515D |
Package Size(L*W*H)cm |
63*43*59 |
Loading Weight(kg) |
69 |
1. JNK 380 kgs high pressure water gun with quick connector 3/8
2. 10 meter double high pressure water outlet pipe with quick connector 3/8
3. CCC GB power cord4 M*1.5mm²
4. 3 Meters inlet water pipe of material of 3 layers rubber, 3lines and 1 steel wire, with 304 double stainless steel filter mesh
5. Nozzles, copper quick connector, 304 stainless steel clips
1. Vehicle cleaning
2. Cleaning outdoor spaces
3. Workshop cleaning
4. Service station cleaning
5. Swimming pool cleaning
6. Fleet washing
7. Steam washing
8. Rail equipment cleaning
9. Heavy equipment cleaning
10. Building cleaning
11. Ware house cleaning
12. Acid&chemical washing
13. Wash station rentals
14. Club root washing
15. Disinfection&sanitizing service
16. High pressure cleaning
17. High pressure rusty removing
18. Pigsty cleaning
19. Poultry cleaning
20. Kitchen cleaning
