The BG series high pressure washer is the most high-performance model in the BG range. The machine operates with Single-phase current operation, features an impressive 10/2.65 flow volume, features an impressive 304 stainless steel clips and four different nozzles, and is synonymous with high durability. All components are designed for continuous use. The intuitive operation, compact dimensions and low weight guarantee comfortable handling.The high pressure pump is made of forged brass and ceramic plungers. The machine is also impressive in terms of efficiency: reduced cleaning times ensure a plus for profit. The machine features easy access to all relevant machines parts.
Technical data
Model |
JNK-BG-28T2 |
JNK-BG-28T |
JNK-BG-213T |
|
Motor Voltage(KW) |
2.4 |
2.5 |
||
Voltage(V) |
220 |
|||
Frequency(HZ) |
50 |
|||
Rotary Speed(rpm) |
2800 |
1450 |
||
Rated Pressure(bar/PSI) |
90/1305 |
130/1885 |
||
Max Pressure(bar/PSI) |
110/1600 |
100/1450 |
110/1600 |
150/2200 |
Flow Volume(L/min /GPM) |
10/2.65 |
14/3.70 |
15/3.96 |
11/2.90 |
Nozzle Model |
040 |
065 |
075 |
040 |
Pump Model |
JNK-1108D |
JNK-1308D |
JNK-1511D |
JNK-1113D |
Package Size(L*W*H)cm |
50*43*28 |
61.5*41.5*30*5 |
||
Loading Weight(kg) |
35 |
46 |
49 |
1. JNK 380 kgs high pressure water gun with connector M22*1.5, inner diameter 14mm/JNK 380 kgs high pressure water gun with quick connector 3/8
2. 10 meter high pressure water outlet pipe with connector M22*1.5, inner diameter 14mm/10 meter high pressure water outlet pipe with quick connector 3/8
3. CCC GB power cord 3M*1.5mm²/CCC GB power cord 3M*2mm²
4. 3 Meters inlet water pipe of material of 3 layers rubber,2/3lines and 1 steel wire, with 304 double stainless steel filter mesh
5. Nozzles and 304 stainless steel clips/Nozzles,copper quick connector, 304 stainless steel clips
1. Vehicle cleaning
